| Parameters |
G5 |
G5 Pro |
| Overall Dimensions (L x W x H) |
36"x22"x37" (920x565x940 mm) |
36"x22"x37" (920x565x940 mm) |
| Folded Dimensions (L x W x H) |
29.5"x22"x12" (750x565x300 mm) |
29.5"x22"x12" (750x565x300 mm) |
| Seat Height (from ground) |
19" (480 mm) |
19" (480 mm) |
| Armrest Height (from seat) |
9" (230 mm) |
9" (230 mm) |
| Backrest Height (from seat) |
19" (490 mm) |
19" (490 mm) |
| Max Loading Weight |
265 lbs (120 kg) |
265 lbs (120 kg) |
| Net Weight without Battery |
46 lbs (20.8 kg) |
40 lbs (18 kg) |
| Net Weight with Battery |
50 lbs (22.6 kg) |
45 lbs (20.5 kg) |
| Battery |
24V 10AH lithium-ion |
24V 10AH lithium-ion |
| Battery Charge |
AC 100-240V, 50Hz, 1.5-5A |
AC 100-240V, 50Hz, 1.5-5A |
| Battery Charge Time |
4 to 8 hours |
4 to 8 hours |
| Range with 12AH Battery |
Up to 10 mile (16 km) |
Up to 13 mile (20 km) |
| Airline and Cruise Approval |
Approved |
Approved |
| Max Speed |
4 mph (6 km/h) |
4 mph (6 km/h) |
| Motor |
2 × 250W Brushed (Total 500W) |
2 × 200W Brushless (Total 400W) |
| Controller |
24V 35A |
24V 40A Brushless |
| Obstacle Climbing |
1.5" (400 mm) |
1.5" (400 mm) |
| Climbing Angle Max Degrees |
10° |
10° |
| Max Safe Slope |
9° |
9° |
| Static Stability |
9° |
9° |
| Brake |
Intelligent electromagnetic brake |
Intelligent electromagnetic brake |
| Turning Radius |
≤ 47" (1200 mm) |
≤ 47" (1200 mm) |
| Reversing Width |
≤ 59" (1500 mm) |
≤ 59" (1500 mm) |
| Front Wheel Diameter |
7" (178 mm) |
7" (178 mm) |
| Rear Wheel Diameter |
11" (280 mm) |
11" (280 mm) |
| Seating Area Width |
18" (460 mm) |
18" (460 mm) |
| Cushion Size (width x depth) |
17.5" (450 mm) × 16.9" (430 mm) |
17.5" (450 mm) × 16.9" (430 mm) |
| Controller Type |
Detachable All-Direction Joystick |
Detachable All-Direction Joystick |
| Tire pressure (for pneumatic tire) |
30 psi (2 kgf/cm²) |
30 psi (2 kgf/cm²) |
