| Weight Capacity: |
400 lbs. |
| Drive Wheels: |
Rear |
| Maximum Speed: |
5.3 mph |
| Operating Range: |
20.9 miles (U1)
25.4 miles (40AH) |
| Ground Clearance Under Deck: |
4.5" |
| Ground Clearance to transaxle/motor: |
2.5" |
| Turning Radius: |
41" |
| Type Batteries: |
2-U1 (Standard)
2-40AH (Optional) |
| Colors: |
Red, Blue |
| Freewheel Mode: |
Yes |
| Electronic Speed Control: |
Yes |
| Electro-Mechanical Brakes: |
Yes |
| Charger: |
Off Board |
| Controller: |
90 Amp |
| Length: |
45.5" |
| Width: |
23.5" |
| Height (ground to top of back seat): |
37" - 39" |
| Ground to Top of Seat: |
24" - 26" |
| Ground to Top of Deck: |
6.25" |
| Deck to Top of Seat: |
18" - 20" |
| Number of Seat Height Positions: |
3 |
| Size of Increments: |
1" |
| Front Axle to Rear Axle: |
34.5" |
| Weight of Unit (assembled): |
176 lbs (U1)
192 lbs (40AH) |
| Front Half: |
56 lbs. |
| Rear Half: |
48 lbs. |
| Seat with Arms: |
26 lbs. |
| Batteries: |
21 lbs. ea. (U1)
19 lbs ea. (40AH) |
| Tires (standard): |
Solid, low profile |
| Front: |
9" |
| Rear: |
10.75" |
| Rear Anti-Tippers: |
3" |
| Standard Seat: |
Stadium Style |
| Slide Seat: |
Standard |
| Back Height No Headrest: |
16" |
| Width x Depth: |
18" x 16" |
| Color: |
Black Vinyl |
| Pneumatic Rise Seat Options: |
Yes |
| Power Elevating Seat Option: |
Yes |
| Frame Warranty: |
Lifetime |
| Drive Train Warranty: |
2 Years |
| Electronics Warranty: |
2 Years |
| Battery Warranty: |
1 Year |
| Disassembles: |
Yes |
| Battery Type: |
U1 |
| Batteries Included: |
Yes |
| Drive Type: |
Rear-Wheel Drive |
